Bullet Projectile Optical Inspection, Measurement & Sorting Machine

Inspection Capabilities

The system uses advanced machine vision inspection technology and automation.

• Overall Length

  Checks total projectile length; detects short/long parts, deformation, dimensional variation.

• Maximum Diameter

  Measures critical outside diameter; detects oversize, undersize and out-of-round conditions.

• Ogive / Nose Profile

  Checks projectile nose contour and profile; detects incorrect shape, deformation and forming defects.

• Nose Tip Condition

  Inspects tip geometry and surface; detects damaged, flattened, chipped or malformed tips.

• Body Profile

  Checks complete external contour; detects dents, bulges, wrinkles and profile variation.

• Concentricity / Symmetry

  Compares projectile axis and external profile; detects eccentricity, asymmetry and off-center forming.

• Surface Finish

  Inspects visible surface quality; detects scratches, pits, stains, marks and manufacturing blemishes.

• Cracks / Fractures

  High-resolution surface inspection; detects visible cracks, splits and fracture lines.

• Dents / Deformation

  Checks cylindrical and curved surfaces; detects dents, flattening and mechanical damage.

• Wrinkles / Forming Marks

  Inspects formed surfaces; detects wrinkles, folds and abnormal forming marks.

• Jacket Surface Condition

  Checks jacket appearance and uniformity; detects scratches, coating variation, dents and surface damage.

• Base / Rear Profile

  Inspects rear-end geometry; detects damaged edges, deformation and incorrect profile.

• Base Diameter

  Measures rear diameter; detects dimensional variation and out-of-round conditions.

• Edge / Rim Condition

  Inspects visible edges; detects burrs, sharp edges, chips and irregularities.

• Foreign Material / Contamination

  Detects unwanted particles or contamination on the surface; identifies dirty or contaminated parts.

• Color / Surface Uniformity

  Checks visual consistency; detects discoloration, stains and abnormal surface appearance.

• Marking / Identification

  OCR/OCV or pattern inspection where applicable; detects missing, incorrect or poorly formed markings.

• Orientation

  Checks part orientation before inspection/sorting; detects incorrectly presented components.

• Presence / Absence of Features

  Verifies required visible features; detects missing or incorrectly formed features.

• Overall Visual Quality

  Combines multiple vision checks into final OK/NG decision; identifies parts outside defined inspection criteria.

• OK / NG Sorting

  OK/NG classification, defect-based classification, dimensional sorting, recipe-based sorting
